48 Core GYTA33 Direct Burial Steel Wire Armored Submarine Underwater Fiber Optic Cable

مقدار حداقل تعداد سفارش : 1 کیلومتر جزئیات بسته بندی : طبل چوبی
زمان تحویل : 3-5 روز شرایط پرداخت : L/C ، D/A ، D/P ، T/T ، Western Union ، MoneyGram
قابلیت ارائه : 8000 کیلومتر در ماه
محل منبع: گوانگدونگ ، چین نام تجاری: JQ/OEM/Customize
گواهی: CE/ISO9001/RoHS/FCC شماره مدل: GYTA33

اطلاعات تکمیلی

نوع کابل: GYTA33 محل مبدا:: گوانگژو ، چین
شمارش فیبر: 2-288 هسته نوع فیبر: G652D Single Mode یا به عنوان درخواست شما
برند فیبر: yofc/fiberhome/corning/fujikura تعداد هادی ها: 10 پوند
عضو قدرت: سیم فلزی/نخ شیشه ای FRP ساختار: شل لوله رشته
زرهی: ژاکت دوتایی زرهی ماده ژاکت: PE یا به عنوان درخواست شما
ساخت کابل: زره نوار آلومینیومی لوله چند گشاد کاربرد: زیر آب زیر آب
دمای کار: -40 ~+60 ℃ نوع اتصال دهنده: SC/FC/ST/LC
ضمانت: بیش از 25 سال مجوزها: گواهینامه های ROHS ، REACH ، SGS و ISO
مادی: فیبر نوری لوله شل: PBT
حالت: حالت تک یا حالت چندگانه غلاف: HDPE/LSZH
نشان: نوار آلومینیومی راه راه تعداد فیبر: 8
سازنده: بله قطر ژاکت: 12.8
استفاده کردن: مجرای/ هوایی/ زیر آب/ دفن مستقیم روش نصب: هوایی
رنگ غلاف بیرون: سیاه
برجسته کردن:

48 core steel wire armored fiber optic cable,direct burial underwater fiber optic cable,GYTA33 submarine fiber optic cable

,

direct burial underwater fiber optic cable

,

GYTA33 submarine fiber optic cable

توضیحات محصول

The GYTA33 optical cable adopts a PBT loose tube design, where the optical fibers are housed and filled with thixotropic gel. At the center of the cable core lies a steel wire strength member, and for cables with higher core counts, a PE cushion layer is added. The loose tubes are stranded around the central strength member in an SZ pattern, with water-blocking compounds filling the interstices. The outer layer is reinforced with round steel wire armor and covered by a polyethylene sheath for enhanced protection.
48 Core GYTA33 Direct Burial Steel Wire Armored Submarine Underwater Fiber Optic Cable 0

The GYTA33 optical cable is designed for deployment in freshwater and shallow water environments. It can be laid directly without joints and is suitable for short-distance underwater communication.

Key Features:

  1. Strong resistance to mechanical stress and temperature variations.

  2. Steel wire armor provides high tensile strength.

  3. Longitudinal aluminum tape wrapping acts as an effective moisture barrier.

  4. Full cross-section water-blocking ensures protection against fresh or salt water intrusion.

  5. Outer jacket shields the cable from UV exposure.

  6. Flame-retardant sheath available upon request.

  7. Reliable operation when installed at depths up to 250 meters.

Product Specifications:
48 Core GYTA33 Direct Burial Steel Wire Armored Submarine Underwater Fiber Optic Cable 1
Package:
24 Core G652D GYTA33 Steel Armored Stranded Loose Tube Optical Fiber Cable
3km/Wooden Drum,Drum dimension 110*55*50cm,G.W 360.0kg.
48 Core GYTA33 Direct Burial Steel Wire Armored Submarine Underwater Fiber Optic Cable 2

FAQ

Q1: Are you a manufacturer or a trading company?
A1: We are a direct manufacturer.



Q2: Where is your factory located? How can I visit?
A2: Our factory is in Shenzhen, Guangdong Province. You can fly to Shenzhen or Guangzhou airport, and provide us with your flight number—we’ll arrange pickup.



Q3: Can I order samples?
A3: Of course! Sample orders are welcome for testing our quality and service.



Q4: What is the warranty period?
A4: All products come with a 12-month warranty.



Q5: What payment options do you support?
A5: We accept L/C, T/T, PayPal, Western Union, and MoneyGram.



Q6: Do you offer OEM/branding services?
A6: Yes, we provide professional OEM service. For bulk orders, custom logo printing is free of charge.
